New DrayTek 5G/4G LTE and Ethernet Security Firewall Routers – Vigor2927L-5G Series

August 23, 2024
Video: DrayTek Vigor2865L-5G router series overview
DrayTek

Overview
  • 5G/4G LTE modem with dual nano SIM slots (SIM slot 2 for Failover) for SA and NSA 5G WAN
  • Support 5G NR Sub-6 SA Band: n1, 3, 5, 7, 8, 20, 28, 38, 40, 77, 78; great coverage in Australia and New Zealand
  • 5G Max. Data Rate NR SA: 2.4Gbps (DL) / 900Mbps (UL)**
  • 5G Max. Data Rate NR NSA: 3.4Gbps (DL) / 550Mbps (UL)**
  • Multi-WAN with 1 x fixed GbE WAN port, 1 x configurable GbE WAN/LAN port, 1 x USB port, 2 x 5G/4G LTE nano SIM slots, and 2 x Wi-Fi WANs for Lax-5G model
  • 1 x fixed GbE WAN port and 1 x configurable GbE WAN/LAN port for Failover, Load Balancing and High Availability mode
  • 1 x USB 2.0 port for connection of 3G/4G LTE USB modem, FTP server, network printer and thermometer
  • 5 x Gigabit LAN ports with multiple subnets and 60,000 NAT sessions
  • 50 x VPN tunnels (including 25 x OpenVPN/ SSL-VPN tunnels) with comprehensive secure protocols
  • Fast VPN throughput, VPN Load Balancing and backup for site-to-site applications
  • Hardware Acceleration and Hardware QoS for up to 8k NAT and routing connections, and 940Mbps (Single WAN) or 1.8Gbps (Multi-WAN) Firewall speed
  • Integrated IEEE 802.11ax (WiFi 6, AX3000) wireless Access Point; dual band; up to 2402 Mbps throughput (Lax-5G model)
  • 16 x VLANs for secure and efficient workgroup management
  • IPv6 & IPv4
  • Up to 1022 IP addresses and 8 IP subnets
  • High Availability mode
  • Object-based SPI Firewall and CSM (Content Security Management) for network security
  • Supports VigorACS 3 Central Management Software for remote management
  • SD WAN capability when used with VigorACS 3
  • Central VPN Management for up to 8 remote Vigor routers Learn more
  • Central AP Management for up to 20 Vigor Access Points Learn more
  • Central Switch Management for up to 10 VigorSwitches Learn more
  • 2 years back to base warranty
**Typical 5G Downlink/Uplink speeds are 400Mbps/200Mbps, depending on the local conditions.
The Vigor2927L-5G series combines 4G LTE and 5G to provide excellent mobile coverage in Australia and New Zealand:

5G/LTE/WCDMA Specifications
5G NR Sub-6 SA Band: n1, 3, 5, 7, 8, 20, 28, 38, 40, 77, 78
5G NR Sub-6 NSA Band: n1, 3, 5, 7, 8, 20, 28, 38, 40, 77, 78
5G Max. Data Rate NR SA: 2.4Gbps (DL) / 900Mbps (UL)**
5G Max. Data Rate NR NSA: 3.4Gbps (DL) / 550Mbps (UL)**
LTE FDD Band: B1, 3, 7, 8, 20, 28
LTE TDD Band: B38, 40
LTE Category: Cat19 (DL) / Cat18 (UL)
WCDMA (3G) Band: B1, 8
WCDMA Max. Data Rate:
42Mbps (DL) / 5.76Mbps (UL)

**Typical 5G Downlink/Uplink speeds are 400Mbps/200Mbps, depending on the local conditions.

5G & WiFi 6 for Next-Gen Connectivity

The Vigor2927L-5G series routers offer most of the features of the Vigor2927 series, with the addition of an integrated 5G/4G LTE mobile broadband Nano SIM module, supporting speeds up to 10 times faster than 4G. This enhanced LTE capability makes the Vigor2927L-5G series routers ideal for applications such as:

  1. Remote location with no fixed line or NBN/UFB coverage
  2. Quick setup for new branches waiting for xDSL/Ethernet WAN (e.g. NBN deployment)
  3. Load Balancing or Failover backup for an existing primary internet connection such as Cable/NBN/ UFB Ethernet broadband
  4. Temporary installations such as disaster recovery, emergency, exhibitions and sporting events where internet access is required for a short period
  5. Providing internet access on public transport such as coaches, buses, trains and freighters
The Vigor2927L-5G series includes one Gigabit Ethernet WAN port, one Gigabit Ethernet WAN/LAN configurable port, five Gigabit Ethernet LAN ports, and a dual Nano SIM card slot for 5G/4G LTE broadband connectivity, allowing for a second Nano SIM to be installed for failover. The WAN ports support NBN technologies including FTTP, HFC, Satellite and Fixed Wireless. All WAN interfaces, including the 3G/4G USB WAN interfaces, can be configured to Load Balance mode or Failover mode.


5G

Support SA and NSA mode

AX3000

(Lax model)
Delivers link rates up to
3 Gbps

50 x VPN tunnels

IPsec VPN throughput up to 250 Mbps

60k NAT sessions

Recommended for a network of up to 50+ devices


Interface

DrayTek DrayTek
  1. 2 x Wireless Antennas (Lax model)
  2. Reset Button
  3. WLAN/WPS Button (Lax model)
  4. 1 x USB 2.0 port for connection of 3G/4G LTE USB modem, FTP server, network printer and thermometer
  5. Fixed WAN Port: 1x GbE RJ-45
  6. WAN/LAN Switchable Port: 1x GbE RJ-45
  7. Fixed LAN Port: 5x GbE RJ-45
  8. 4x LTE Antenna
  9. Power Input
  10. Power On/Off Switch
  11. 2 x Nano-Sized SIM Slots (SIM slot 2 for Failover)
5G Router with High Speed Mobile Connectivity lte_backward_to_4g
* Backward compatible to 4G LTE
  • The integrated 5G/LTE modem with Category 19 supports carrier aggregation, providing high-speed mobile broadband connectivity for Internet access and VPN.
  • The dual SIM slot accepts two SIM cards from different mobile network providers. This ensures that the router can seamlessly switch to the secondary SIM and cellular network if the primary mobile connectivity is broken.
  • The four LTE antennas with 1-metre extension cables make it easy to place the router at locations that ensure the best possible signal coverage.
Multi-WAN 5G Gigabit Security Router with Load Balance

WAN Load Balancing

The Vigor2927L-5G Series supports high throughput from Gigabit Internet connectivity via Fibre to the Premises (FTTP) and 5G LTE mobile connections. All active WANs automatically join the WAN Load Balance pool to optimize bandwidth utilisation

Seamless Failover

If an Internet connection is lost, the router automatically switches to surviving WAN connections, seamlessly transferring traffic. This ensures reliable Internet connectivity and avoids the costs associated with network downtime

Policy-Based Routing

Routing policies can be used to designate specific WAN interfaces for traffic from or to certain IP ranges and for applications such as VoIP thus enhancing network efficiency and performance. wan_loadbalance_lte
Ideal VPN Router for SMB

Ideal VPN Router for SMB

  • Up to 800 Mbps hardware-accelerated IPsec VPN performance
  • Up to 50 active VPN tunnels concurrently

All common VPN standards are supported

  • WireGuard VPN (from firmware v4.4.3)
  • IKEv1/IKEv2 EAP/ SSL VPN/ L2TPoverIPsec/ PPTP/OpenVPN

Advanced Authentication for Teleworker

  • Two-factor authentication for teleworker VPN connections
  • Authentication can be integrated with Active Directory (LDAP), RADIUS, or TACACS+ servers in the network as required
  • Network administrators can be notified via SMS/Email when a teleworker VPN is online, preventing VPN credential loss or misuse by others

DrayTek
Hotspot Web Portal
 DrayTek
Market your business while offering free Wi-Fi

Wi-Fi Marketing

Redirect hotspot guests to the company homepage, online surveys, or display a promotion message.

Grow Customer Mailing List

Require guests to leave contact info or social media accounts before they can use the Internet services.

Various Authentication Types

A variety of login methods are supported to meet your business needs, including Facebook Login, Google Login, SMS PIN, Voucher PIN, and RADIUS.

3rd-Party Service Compliant

Supports external captive portal authentication so you can keep using the Wi-Fi marketing solution you prefer.

Data Quota Management

Bandwidth management is integrated into the Hotspot features to control the bandwidth and session usage of the Hotspot guests.

Comprehensive Firewall

Object-based Firewall

IPs and services can be grouped into objects before being applied to firewall rules. This feature simplifies the organisation of network activities.


Blocking Apps & DoH servers

APP Enforcement (APPE) allows the blocking of applications (IM, P2P, streaming, tunnelling, etc.) on a LAN network quickly and easily. For example, by blocking DoH servers in browsers, LAN clients can only use standard DNS queries and filtering.


Manage Traffic Beyond LAN to WAN

DrayTek Firewall manages not only traffic between LAN and WAN, but also those between LAN subnets, remote VPN subnets, and from WAN to the Vigor router itself. Internet IPs can be predefined for accessing the Vigor routers’ services, enhancing security and control.


Web Content Filtering with DNS Filter

The Web Content Filtering Service uses cloud-based technology to provide comprehensive and up-to-date protection for LAN clients for online activities, with 82 categories in total, 10 of which are security-focused.

DrayTek

Edge Router for SD-WAN

Edge Router for SD-WAN

Latency, loss, and jitter measure the quality of every WAN/VPN interface. Based on these metrics, the Vigor2927L-5G can dynamically self-adjust to the best-quality interface for VoIP and business-critical applications.

DrayTek

Application Visibility and SD-WAN Policy

Application Visibility enables the network administrator to monitor data usage sorted by client, WAN interface, application, and time.

With data usage details, SD-WAN policies can be created to route business-critical applications through the best-quality interfaces to improve the user experience.


DrayTek
App QoSApplication QoS allows prioritisation of applications and services on DrayTek routers to improve and enhance critical applications such as VoIP, conferencing and video streaming, etc. It also allow flexible bandwidth allocation to suit business requirements.

VoIP First

VoIP is always a top priority! The default VoIP port, UDP 5060 (configurable) has priority out-of-box with QoS.

Improve Experience for Business-Critical Apps

Select your business critical apps, and easily put them into QoS classes.

Flexible Bandwidth Allocation

Bandwidth will be reserved for high-priority classes, and can be used by low-priority classes when available.DrayTek
Learn More
Key Features

Embedded SIM Slot
Provide 4G LTE/5G Internet access to where fixed lines are (temporarily) not available without the need for a USB dongle.

Load Balancing
Maximize throughput and reliability by using multiple Internet connections. Learn more

VPN (Virtual Private Network)
Build a secure and private tunnel from the LAN of Vigor2927L-5G series to the remote offices and teleworkers over the Internet. Learn more

SSL VPN
The VPN works through firewalls providing secure remote access to any network environment. Learn more

VPN Matcher
Helps routers behind NAT to find each other and establish a LAN-to-LAN VPN. Learn more.

Firewall & Content Filter
Filter web pages by URL keywords or web category to block access to insecure or inappropriate content.

VoIP Friendly
Vigor2927L-5G Series can do port forwarding and reserve bandwidth for VoIP traffic automatically, making VoIP setup effortless. Setup Guide

Bandwidth Management
Prevent one device using all the bandwidth by bandwidth limit policy, session limit policy, and QoS settings.

Hotspot Web Portal
Market your business and communicate with the guests while offering hospitality WLAN. Learn more

Wireless WAN (Lax model only)
Get Internet access wirelessly from a wireless network, a mobile hotspot, or a personal hotspot set up on smartphones. Learn more

DrayDDNS
The free DDNS service for you to access the router by a fixed hostname of your choice. Learn more

Central AP Management
Use the Vigor2927L-5G Series router as a wireless controller to maintain and monitor the VigorAPs. Learn more

Mesh (Lax model only)
Easily link to other VigorAP to expand the wireless network. Learn more.

Central Switch Management
Set up VLAN easily from the router and get a centralized hierarchy view of the switches. Learn more

All-in-One Management

Mesh Management

DrayTekMesh (Vigor2927Lax-5G only)
Up to 7 APs
  • DrayTek Wireless app-support
  • Discovery
  • Auto-Provisioning
  • Monitoring
  • Centralized Hierarchy View

Vigor Router SWM

DrayTek
Central Switch Management
Up to 10 switches
  • Auto-Discovery
  • Auto-Provisioning
  • Monitoring
  • Centralized Hierarchy View
  • Reboot PoE Devices Remotely
  • Quick VLAN Configuration

Vigor Router APM

DrayTek
Vigor Router APM
Up to 20 APs
  • Auto-Discovery
  • Auto-Provisioning
  • Monitoring
  • Centralized View
  • Alarm
  • Reboot VigorAP Remotely
  • Wi-Fi Client Load Balancing
Software Management

VigorACS 3

DrayTek
VigorACS 3

  • Zero Touch Deployment & Provisioning
  • Auto VPN
  • Interface Quality & SLA
  • VoIP Optimization & Monitoring
  • Application Visibility
  • Application Based SD-WAN Policy
  • Customized Hotspot Page with Multilingual
  • Hotspot Clients Analytics
  • ACS Server Load Balancing / Failover
In-the-box
 DrayTek Webinar


Note :

The throughput figures are maximum, based on DrayTek internal testing with optimal conditions. The actual performance may vary depending on the different network conditions and applications activated.
Models
Vigor2927Lax-5G
Multi-WAN router with a dual 5G Nano SIM card slot, I x GbE WAN port, 1 x configurable GbE WAN/LAN port, 5 x GbE LAN ports, SPI Firewall, 802.11ax (WiFi 6, AX3000) and 50 x VPN tunnels including 25 x Open VPN/SSL VPN tunnels
DrayTek_vigor2927Lax-5G
  • 5G/4G LTE modem with dual nano SIM slots (SIM slot 2 for Failover) for SA and NSA 5G WAN
  • Support 5G NR Sub-6 SA Band: n1, 3, 5, 7, 8, 20, 28, 38, 40, 77, 78; great coverage in Australia and New Zealand
  • 5G Max. Data Rate NR SA: 2.4Gbps (DL) / 900Mbps (UL)**
  • 5G Max. Data Rate NR NSA: 3.4Gbps (DL) / 550Mbps (UL)**
  • Multi-WAN with 1 x fixed GbE WAN port, 1 x configurable GbE WAN/LAN port, 1 x USB port, 2 x 5G/4G LTE nano SIM slots, and 2 x Wi-Fi WANs for Lax-5G model
  • 1 x fixed GbE WAN port and 1 x configurable GbE WAN/LAN port for Failover, Load Balancing and High Availability mode
  • 1 x USB 2.0 port for connection of 3G/4G LTE USB modem, FTP server, network printer and thermometer
  • 5 x Gigabit LAN ports with multiple subnets and 60,000 NAT sessions
  • 50 x VPN tunnels (including 25 x OpenVPN/ SSL-VPN tunnels) with comprehensive secure protocols
  • Fast VPN throughput, VPN Load Balancing and backup for site-to-site applications
  • Hardware Acceleration and Hardware QoS for up to 8k NAT and routing connections, and 940Mbps (Single WAN) or 1.8Gbps (Multi-WAN) Firewall speed
  • Integrated IEEE 802.11ax (WiFi 6, AX3000) wireless Access Point; dual band; up to 2402 Mbps throughput (Lax-5G model)
  • 16 x VLANs for secure and efficient workgroup management
  • IPv6 & IPv4
  • Up to 1022 IP addresses and 8 IP subnets
  • High Availability mode
  • Object-based SPI Firewall and CSM (Content Security Management) for network security
  • Supports VigorACS 3 Central Management Software for remote management
  • SD WAN capability when used with VigorACS 3
  • Central VPN Management for up to 8 remote Vigor routers Learn more
  • Central AP Management for up to 20 Vigor Access Points Learn more
  • Central Switch Management for up to 10 VigorSwitches Learn more
  • 2 years back to base warranty
**Typical 5G Downlink/Uplink speeds are 400Mbps/200Mbps, depending on the local conditions.
Vigor2927L-5G
Multi-WAN router with a dual 5G Nano SIM card slot, I x GbE WAN port, 1 x configurable GbE WAN/LAN port, 5 x GbE LAN ports, SPI Firewall and 50 x VPN tunnels including 25 x Open VPN/SSL VPN tunnels
DrayTek
  • 5G/4G LTE modem with dual nano SIM slots (SIM slot 2 for Failover) for SA and NSA 5G WAN
  • Support 5G NR Sub-6 SA Band: n1, 3, 5, 7, 8, 20, 28, 38, 40, 77, 78; great coverage in Australia and New Zealand
  • 5G Max. Data Rate NR SA: 2.4Gbps (DL) / 900Mbps (UL)**
  • 5G Max. Data Rate NR NSA: 3.4Gbps (DL) / 550Mbps (UL)**
  • Multi-WAN with 1 x fixed GbE WAN port, 1 x configurable
    GbE WAN/LAN port, 1 x USB port, and 2 x 5G/4G LTE nano
    SIM slots
  • 1 x fixed GbE WAN port and 1 x configurable GbE WAN/LAN port for Failover, Load Balancing and High Availability mode
  • 1 x USB 2.0 port for connection of 3G/4G LTE USB modem, FTP server, network printer and thermometer
  • 5 x Gigabit LAN ports with multiple subnets and 60,000 NAT sessions
  • 50 x VPN tunnels (including 25 x OpenVPN/ SSL-VPN tunnels) with comprehensive secure protocols
  • Fast VPN throughput, VPN Load Balancing and backup for site-to-site applications
  • Hardware Acceleration and Hardware QoS for up to 8k NAT and routing connections, and 940Mbps (Single WAN) or 1.8Gbps (Multi-WAN) Firewall speed
  • 16 x VLANs for secure and efficient workgroup management
  • IPv6 & IPv4
  • Up to 1022 IP addresses and 8 IP subnets
  • High Availability mode
  • Object-based SPI Firewall and CSM (Content Security Management) for network security
  • Supports VigorACS 3 Central Management Software for remote management
  • SD WAN capability when used with VigorACS 3
  • Central VPN Management for up to 8 remote Vigor routers Learn more
  • Central AP Management for up to 20 Vigor Access Points Learn more
  • Central Switch Management for up to 10 VigorSwitches Learn more
  • 2 years back to base warranty
**Typical 5G Downlink/Uplink speeds are 400Mbps/200Mbps, depending on the local conditions.
Config Demo
video image
Click here to the Config Demo Page
video image

Webinars:

Videos:

Learn More

Recent posts
