VigorSwitch Q1070x
DSQ1070x
- 7-Port Smart Lite Managed Gigabit Switch
- 5 x 2.5 Gigabit Ethernet Ports
- 2 x 10GbE SFP+ Ports
- 65 Gbps switching capacity
- Port based and 802.1q tagged VLANs
- QoS with 4 queues for traffic prioritisation
- Fan-less (Silent) Operation
- 2 years back-to-base warranty
Performance
Buffer Size
8 Mbit
Switching Capacity
65 Gbps
Forwarding Rate (64 bytes)
48.36 Mpps
MAC Address Table
16k
Jumbo Frame (MAX)
10 KB
L3 Routing Table
Number of Ports
2.5 GbE Ports
5
SFP+ (10G) Ports
2
LAN
Spanning Tree
- STP ,
- RSTP
[Switch] - ONVIF Surveilance
VLAN
Tag-Based VLAN
✔
MAC-Based VLAN
Voice & Surveilance VLAN
GVRP
QinQ (Basic)
Layer3 Features
Static Route
VLAN Route
DHCP Server
Security
IP Conflict Detection & Prevention
IP Source Guard
Access Control List
802.1X/MAC Authentication
Dynamic ARP Inspection (DAI)
DHCP Snooping
Muticast
IGMP Snooping
v2, v3(BISS)
MLD Snooping (Basic)
v1, v2
Management
sFlow
SNMP
v1, v2c
LLDP
✔
LLDP-MED
Managed by Vigor Router
Managed by VigorConnect
Managed by VigorACS
