Vigor2865L-5G
DV2865L5G
- 5G/4G LTE modem with dual nano SIM slots (SIM slot 2 for Failover) for SA and NSA 5G WAN
- Support 5G NR Sub-6 SA Band: n1, 3, 7, 8, 20, 38, 40, 77, 78
- 5G Max. Data Rate NR SA: 2.4Gbps (DL) / 900Mbps (UL)
- Support 5G NR Sub-6 NSA Band: n1, 3, 7, 8, 20, 38, 40, 77, 78
- 5G Max. Data Rate NR NSA: 2.8Gbps (DL) / 555Mbps (UL)
- Multi-WAN with 1 x VDSL2 modem, 1 x configurable GbE WAN/LAN port, 1 x USB port, and 2 x 5G/4G LTE nano SIM slots
- 1 x VDSL2 modem and 1 x configurable GbE WAN/LAN port for Failover, Load Balancing and High Availability mode
- 1 x USB 2.0 port for connection of 3G/4G LTE USB modem, FTP server, network printer and thermometer
- 5 x Gigabit LAN ports with multiple subnets and 60,000 NAT sessions
- 32 x VPN tunnels (including 16 x OpenVPN/ SSL-VPN tunnels) with comprehensive secure protocols
- Fast VPN throughput, VPN Load Balancing and backup for site-to-site applications
- Hardware Acceleration and Hardware QoS for up to 8k NAT and routing connections, and 940Mbps (Single WAN) or 1.8Gbps (Multi-WAN) Firewall speed
- 16 x VLANs for secure and efficient workgroup management
- IPv6 & IPv4
- Up to 1022 IP addresses and 8 IP subnets
- High Availability mode
- Object-based SPI Firewall and CSM (Content Security Management) for network security
- Supports VigorACS 3 Central Management Software for remote management
- SD WAN capability when used with VigorACS 3
- Central VPN Management for up to 8 remote Vigor routers
- Central AP Management for up to 20 Vigor Access Points
- Central Switch Management for up to 10 VigorSwitches
- 2 years back to base warranty
Performance
NAT Throughput
800 Mbps
Hardware Acceleration (NAT)
1.8 Gbps
IPsec VPN Performance
290 Mbps
SSL VPN Performance
120 Mbps
WAN
VDSL2 35b
No, I want to amend it.
G.fast
Ethernet (GbE)
1 x GbE
Switchable WAN/LAN (GbE)
- 1 x GbE (RJ-45)
4G/LTE (via USB)
1 x USB 2.0
4G/LTE (Built-in)
No, I want to amend it.
5G (Built-in)
No, I want to amend it.
Wireless WAN
LAN
Fixed LAN (RJ-45, GbE)
5
LAN Subnet
8
Wireless LAN
2.4G (802.11b/g/n)
2.4G (802.11ax)
5G (802.11a/n/ac)
5G (802.11ax)
Mesh
VPN
Max. VPN
32
Max. OpenVPN + SSL VPN
16
Others
NAT Session
60K
Routing: Static Route
No, I want to amend it.
Routing: RIP
No, I want to amend it.
Routing: BGP
No, I want to amend it.
Routing: Policy Route
No, I want to amend it.
Routing: OSPF
Bandwidth Management
No, I want to amend it.
Content Filter
No, I want to amend it.
DrayDDNS
No, I want to amend it.
Hotspot Web Portal
4 Profiles
VoIP
High Availability
No, I want to amend it.
Rak Mountable
No, I want to amend it.
Management
VPN Management
8 nodes
AP Management
20 nodes
Switch Management
10 nodes
Managed by VigorACS
No, I want to amend it.
Introducing DrayTek 5G Routers
DrayTek has just released 5G routers offering faster internet speeds over the 5G network. In this webinar, we review the differences between the older 4G LTE routers and the newer 5G routers, as well as highlighting the features.
